| Parameter | Specification |
|---|---|
| Structure | Quadruped Lattice (Pyramidal Base) |
| Material | Q345B Carbon Steel (ASTM A572 Gr.50 Equivalent) |
| Height Range | 30m–120m+ (Modular Sections) |
| Wind Speed Rating | 210 km/h (58 m/s) with Antennas |
| Ice Load | 40mm Radial Ice (ISO 12494) |
| Corrosion Protection | Hot-Dip Galvanizing (≥86μm, ASTM A123) |
| Foundation Type | Concrete Pile/Raft (Optimized for Soil Load) |
| Design Life |
50+ Years (Zero Structural Fatigue) |
_1754287401_WNo_600d364.webp)
Unmatched Stability
4-Leg Geometry: Distributes load evenly across foundations, reducing soil pressure by 35% vs. 3-legged designs.
Diagonal Bracing: Redundant K-bracing eliminates torsion under asymmetric antenna loads.
Heavy-Duty Payload Capacity
Supports 6–12 antennas per platform + microwave dishes.
Max Top Load: 5,000 kg (e.g., 5G mMIMO + backup generators).
Extreme Environment Resilience
Seismic: Zone 4 compliance (IBC 2018) with flexible joint design.
Cyclone/Typhoon: Aerodynamic lattice reduces wind drag by 25%.
Why Choose Us?
1.We have a strict quality management system and are certified to ensure that our customers will not have any problems when receiving and using the goods.
2.Imported advanced production equipment can ensure sufficient productivity and good operational stability, ensuring on-time delivery of quality and quantity for our customers.
3.Our long-term accumulation in this industry has given us a good reputation and credibility, and our high-quality products can be seen in major regions of the world.
Hot-dip Galvanization
Hot-dip galvanization thickness over 100 microns, having strong anti-rust and anti-corrosion capabilities. The processing is strictly according to ASTM A123 standard.
Package Reference
_1754287963_WNo_1200d900.webp)
_1754287993_WNo_1200d900.webp)
XH Tower Co., Ltd: Building Global Connectivity with Excellence
Established in 2007 and headquartered in Qingdao, Shandong Province, China XH TOWER Co., Ltd is a leading manufacturer specializing in high-quality telecommunication towers, transmission towers, and steel tower components. With over 17 years of industry expertise, we are committed to delivering innovative engineering solutions and superior products that meet global standards, empowering infrastructure development across the world.
