A V-Boom Bracket is a specialized antenna mount for monopoles that positions two directional antennas in a V-shaped configuration (typically 30°–90° apart). This design optimizes coverage in high-capacity sectors while minimizing wind load and physical footprint. Key applications include:
Sector splitting (e.g., dividing a 120° sector into two 60° sub-sectors)
MIMO antenna pairing for 4G/5G networks
Dual-polarization setups (±45° cross-polarization)
| Component | Material/Specs | Function |
|---|---|---|
| Base Collar | Cast aluminum/Stainless steel (ASTM A276) | Anchors to monopole; distributes load |
| V-Arms | Tapered aluminum tubes (6061-T6) | Supports antennas at precise angles |
| Tilt Mechanism | Adjustable gussets (±15° range) | Fine-tunes vertical coverage |
| Antenna Clamps | Radome-compatible U-bolts (316 SS) | Secures antennas; torque-limited (50 N·m) |
| Cable Entry Ports | IP67-rated glands | Protects RF jumpers from weather |
Arm Length: 1.5–4m (scales with antenna size)
V-Angle: 30°/45°/60°/90° (customizable)
Pole Diameter Compatibility: 3"–18" (76–457mm)
