| Parameter | Specification |
|---|---|
| Material | High-Strength Carbon Steel (Q345B) |
| Height Range | 10m–50m (Standard); Up to 80m (Custom) |
| Diameter | 300mm–1200mm (Tapered Design) |
| Wind Speed Rating | 200 km/h (55 m/s) with Antennas |
| Corrosion Protection | Hot-Dip Galvanizing (≥86μm, ASTM A123) |
| Design Life | 40+ Years (Zero Structural Maintenance) |
| Foundation | Compact Concrete Pad (3m x 3m) |
_1754291811_WNo_700d458.webp)
Space-Saving Design
Minimal footprint (1/5th of lattice towers) – ideal for dense urban areas, rooftops, and roadside installations.
Heavy-Duty Payload
Supports 4–8 sector antennas + microwave links (max. top load: 3,000 kg).
Rapid Deployment
Installation in <8 hours (crane-assisted) vs. days for lattice towers.
Triple-Layer Protection:
Layer 1: 86μm zinc coating (ASTM A123).
Layer 2: Chromate passivation (ISO 4520).
Layer 3: Organic sealant (ISO 12944) → Total corrosion resistance >30 years in C5 marine/industrial environments.
Conical Sections (Patent ZL202310XXXXXX):
20% weight reduction vs. cylindrical monopoles.
Optimized wind vortex shedding (CFD-validated).
Flange-Mounted Platforms: Pre-drilled for mMIMO antennas (64T64R).
EMI-Shielded Conduits: Fiber/coaxial routing without signal interference.
Product Details
(1)_1754292058_WNo_1493d1120.webp)
_1754292094_WNo_600d438.webp)
_1754292115_WNo_600d393.webp)
_1754292148_WNo_800d501.webp)
Why Choose Us?
1.We have a strict quality management system and are certified to ensure that our customers will not have any problems when receiving and using the goods.
2.Imported advanced production equipment can ensure sufficient productivity and good operational stability, ensuring on-time delivery of quality and quantity for our customers.
3.Our long-term accumulation in this industry has given us a good reputation and credibility, and our high-quality products can be seen in major regions of the world.
Hot-dip Galvanization
Hot-dip galvanization thickness over 100 microns, having strong anti-rust and anti-corrosion capabilities. The processing is strictly according to ASTM A123 standard.
Package Reference
_1754292386_WNo_800d600.webp)
_1754292420_WNo_800d600.webp)
_1754292453_WNo_1200d900.webp)
XH Tower Co., Ltd: Building Global Connectivity with Excellence
Established in 2007 and headquartered in Qingdao, Shandong Province, China XH TOWER Co., Ltd is a leading manufacturer specializing in high-quality telecommunication towers, transmission towers, and steel tower components. With over 17 years of industry expertise, we are committed to delivering innovative engineering solutions and superior products that meet global standards, empowering infrastructure development across the world.
