A guyed mast antenna and microwave tower is a reliable and cost-effective solution for supporting antennas and microwave communication equipment. Its design, with guy wires providing stability, makes it suitable for various telecommunication applications, including cellular networks, broadcasting, and microwave communication links. Regular maintenance and inspections are essential to ensure the tower's safety and longevity.
| Parameter | Specification |
|---|---|
| Height Range | 60–300m (200–1,000 ft) |
| Mast Type | Tubular steel (Ø150–600mm) or lattice sections |
| Guy Levels | 3–5 tiers (3–5 wires/tier) |
| Guy Wire | EHS steel (Ø12–36mm), 1,550+ MPa tensile strength |
| Anchor Radius | 60–80% of height (e.g., 48m for 60m tower) |
| Payload Capacity | 500–2,000 kg (antennas + dishes) |
| Wind Survival | 210 km/h (130 mph) |
| Foundation | Central pad (4m×4m) + 3–5 anchor blocks (3–8m³) |
Product Details
_1753233348_WNo_600d443.webp)
| Application | Typical Payload | Mounting |
|---|---|---|
| Long-Haul Microwave | 4–8x 1.2–4m dishes | Top platform + mid-level rings |
| Broadcast Antennas | FM/AM radiators + top-loaded wire arrays | Side-mounted insulators |
| Cellular Macro | 6–12 sector antennas (4G/5G) | Triangular platforms |
| Military Comms | SATCOM terminals + troposcatter | EMI-shielded enclosures |
| Sector | Use Case | Height Benefit |
|---|---|---|
| Telecom | Rural backhaul (20–80km microwave hops) | Clears terrain obstructions |
| Broadcast | 100kW FM radio coverage (150km radius) | Extended line-of-sight |
| Aviation | ILS/VOR navigation aids near airports | FAA obstruction clearance |
| Military | Over-the-horizon radar (OTH-R) platforms | Low radar cross-section |
Hot-dip Galvanization
Strictly according to ASTM-A123 Standard, minum zinc thickness over 85 microns.
Package Reference
_1753233940_WNo_1200d900.webp)
_1753233967_WNo_800d860.webp)
_1753233989_WNo_1200d900.webp)
XH Tower Co., Ltd: Building Global Connectivity with Excellence
Established in 2007 and headquartered in Qingdao, Shandong Province, China XH TOWER Co., Ltd is a leading manufacturer specializing in high-quality telecommunication towers, transmission towers, and steel tower components. With over 17 years of industry expertise, we are committed to delivering innovative engineering solutions and superior products that meet global standards, empowering infrastructure development across the world.
