Heights: The standard heights of these poles include 7m (23 ft), 9m (29.5 ft), and 10m (32.8 ft), catering to medium-voltage distribution lines (e.g., 11kV–33kV).
Shape and Profile: Poles are typically conical, octagonal, or polygonal in cross-section, optimizing structural efficiency and wind resistance.
Thickness: Wall thickness ranges from 2.5mm to 5.0mm, depending on the required mechanical strength and load capacity.
Sections: Poles up to 10m are often single-section designs for easy transport and installation, though taller poles may require multi-segment designs.
Steel Grade: Commonly made from Q235 (equivalent to ASTM A36) or Q355 (equivalent to ASTM A572 Grade 50), with minimum yield strengths of 235 MPa and 345 MPa, respectively.
Welding Standards: Welding complies with AWS D1.1 standards, ensuring high structural integrity and fatigue resistance.
Modularity: Designs often include slip joints or flange connections for easy assembly and field installation.
_1756285202_WNo_1991d1120.webp)
Process: Hot-dip galvanization per ASTM A123 or GB/T 13912-2002 standards, applying a zinc coating of ≥85 µm to ensure longevity.
Durability: Galvanizing provides excellent resistance to rust, moisture, and UV radiation, making these poles suitable for coastal, industrial, and desert environments.
Lifespan: Expected service life of 20–30 years with minimal maintenance, reducing lifecycle costs.
Wind Resistance: Designed to withstand wind speeds of ≥160 km/h (e.g., typhoon-prone regions).
Load Capacity: Vertical loads (e.g., conductors, equipment) typically range from 500 kgf to 1,000 kgf, depending on pole height and design.
Seismic Resilience: Engineered for seismic resistance up to 8 degrees on the Richter scale
Product Details
_1756285379_WNo_700d466.webp)
_1756285407_WNo_600d450.webp)
_1756285427_WNo_800d600.webp)
Production Procedure
_1750985893_WNo_946d225.webp)
_1750985931_WNo_940d224.webp)
Package Reference
_1750987748_WNo_800d800.webp)
_1750987789_WNo_1200d900.webp)
_1750987847_WNo_1200d900.webp)
XH Tower Co., Ltd: Building Global Connectivity with Excellence
Established in 2007 and headquartered in Qingdao, Shandong Province, China XH TOWER Co., Ltd is a leading manufacturer specializing in high-quality telecommunication towers, transmission towers, and steel tower components. With over 17 years of industry expertise, we are committed to delivering innovative engineering solutions and superior products that meet global standards, empowering infrastructure development across the world.
