The guyed wire tower is composed of a tower head, a column and a cable. The tower head and columns are generally made of space trusses composed of angle irons, which have good overall stability and can withstand large axial pressure.
| Code: | XHT23 |
| Categories: | Transmission Tower |
| Unit: | Metric Ton |
| Origin: | Shandong, China |
| Port: | Qingdao, China |
| Pay: | T/T, L/C, D/P |
A 45M Guyed Wire Tower for Telecommunication is a cost-effective, tall, and slender structure designed to support antennas, microwave dishes, remote radio units (RRUs), and other wireless communication equipment for cellular networks, microwave backhaul, broadcasting, and public safety systems. Supported by guy wires (tensioned cables anchored to the ground), this lattice tower or mast provides stability and height for GSM, 3G, 4G LTE, 5G, and radio communication, offering wide-area coverage (5-10 km radius, depending on terrain and frequency bands). Typically constructed from galvanized steel (e.g., Q235B, Q345B, ASTM A572), it is ideal for rural, suburban, or space-abundant urban areas due to its economical design and large footprint for guy wire anchors. Below is a detailed explanation incorporating relevant keywords and industry-standard information from web sources, ensuring alignment with telecommunication infrastructure standards.
| Product Name | 45M Guyed Wire Tower |
| Type | Telecommunication Tower |
| Design Software | MS TOWER, ASM TOWER, PLS TOWER, SAP2000 ETC. |
| Height | 9M-210M |
| Wind Speed | 0--330KM/H |
| Design Standard | TIA/EIA-222-G/F/H |
| Material |
GB/T700: Q235B, GB/T1591: Q355B, Q355C, Q355D, Q420 ASTM A36, ASTM A575, GR50 EN/0025: S235JR, S235JO, S235JZ EN/0025: S355JR, S355JO, S355JZ |
| Certificate | ISO9001:2008 SGS COC |
| Galvanized | Hot-dipped Galvanized |
| Galvanization | ASTM A123/150 1461 |
| Nuts or Bolts | Grade 8.8 |
| Welding | AWS D1.1 |
| Method | CO2 Shielded Arc Welding, Submerged Arc Welding (SAW) |
| Galvanization Standard of Bolts and Nuts | ISO146 OR ASTM/A153 |
| Life Time | More than 25 years |
| Supply Ability | 2,500 Tons Per Month |
_1750906930_WNo_800d800.webp)
_1750906959_WNo_800d800.webp)
_1750907008_WNo_600d443.webp)
The 45M Guyed Wire Tower supports diverse telecommunication and infrastructure needs:
Cellular Networks: Hosts 2G, 3G, 4G LTE, and 5G antennas for mobile connectivity, covering 5-10 km in rural or suburban areas.
Microwave Backhaul: Supports point-to-point microwave dishes for data transmission, connecting remote sites to core networks.
Broadcasting: Elevates FM radio, television, or digital broadcast antennas for regional coverage.
Public Safety: Supports two-way radio systems, emergency networks, or meteorological instruments for first responders and weather monitoring.
Navigation: Hosts VHF/UHF antennas for aviation or maritime communication.
Rural Connectivity: Provides broadband access in geographically wide areas, supporting smart agriculture or IoT networks.
