Height-Specific Configurations
20M Tower: Typically used for compact deployments (e.g., urban areas). Example: Chengdu’s 20m octagonal steel tower for X-band radar, supporting antennas at 20.7m height.
25M Tower: Common for regional weather monitoring. Hangzhou Yuhang uses a 25m straight-section lattice tower with a top platform for dual-polarization radar and equipment cabins at the base.
30M Tower: Maximizes coverage (50–100 km). Jiaozuo’s project leases 30m angular steel towers for X-band radar, emphasizing rapid deployment.
Military-Grade HDG Steel
Corrosion Resistance: Hot-dip galvanized (HDG) coating (≥86 μm) ensures 50-year service life in coastal/high-salt environments.
Modularity: Segmented sections with flange/bolt connections enable field assembly in <72 hours. Foundations range from 18m×18m concrete bases (25m towers) to compact seismic-resistant designs.
Product Details:
_1750842809_WNo_800d600.webp)
_1750842835_WNo_600d704.webp)
_1750842867_WNo_600d450.webp)
_1750842907_WNo_600d450.webp)
_1750842945_WNo_800d600.webp)
| Parameter | 20M Tower | 25M Tower | 30M Tower | |
|---|---|---|---|---|
| Installation Time | 48 hours | ≤72 hours | ≤72 hours | |
| Typical Cost | ~¥220,000 | ~¥254,100 | ~¥300,000+ (lease) | |
| Use Cases | Urban emergency radar | Regional climate stations | Border surveillance | |
| Logistics | Truck transport | Modular helicopter lift | Mobile hydraulic erection |
ASTM Standard Galvanization
Before loading, we will once again show the customer the thickness of the zinc layer at each part to ensure that the galvanizing met the ASTM-A123 standard. Standard packaging is used for sea transportation.
_1752646361_WNo_700d700.webp)
Package Reference
_1755151984_WNo_700d525.webp)
_1755152022_WNo_600d450.webp)
_1755152075_WNo_600d450.webp)
XH Tower Co., Ltd: Building Global Connectivity with Excellence
Established in 2007 and headquartered in Qingdao, Shandong Province, China XH TOWER Co., Ltd is a leading manufacturer specializing in high-quality telecommunication towers, transmission towers, and steel tower components. With over 17 years of industry expertise, we are committed to delivering innovative engineering solutions and superior products that meet global standards, empowering infrastructure development across the world.
